For the Design & Process Engineer:
This collection empowers you with:
- Standardized Data for Efficient Design: Ensures data integrity and consistency across projects, reducing design errors and rework.
- Rapid Specification Development: Leverage extensive pre-defined component properties to accelerate instrument and control specification creation.
- Streamlined Collaboration: Easily share and collaborate on design information with team members using the familiar Excel format.
- Reduced Project Risk: Minimize errors and omissions in documentation, leading to safer and more reliable process designs.
- Full Customization: Adapt datasheets to meet the specific requirements of your company and projects.
Detailed Component Coverage:
This extensive set includes a wide range of instrument and control devices, covering much of your needs from field instrumentation to final control:
- Analytical Instrumentation: Process analyzers for continuous or batch measurements, covering parameters like pH, ORP, conductivity, dissolved oxygen, turbidity, and specific gas components. Specific components covered include sensors, transmitters, monitors, and complete analyzer systems.
- Final Control Elements: Control valves (linear and rotary), including pneumatic, hydraulic, and electric actuators, positioners, smart valve controllers, solenoids, and associated limit switches. Also includes pressure regulators with various pilot designs, and relief valves for overpressure protection.
- Flow Measurement: Covering a wide array of flow technologies such as differential pressure transmitters (orifice plates, Venturi tubes, flow nozzles, etc.), positive displacement meters, turbine meters, vortex flowmeters, ultrasonic flowmeters (Doppler and transit-time), Coriolis mass flowmeters, magnetic flowmeters, and a variety of flow switches.
- Level Measurement: Addressing diverse level applications with hydrostatic (differential pressure), capacitance, radar (FMCW, pulse), guided wave radar (GWR), ultrasonic, displacer, and float-based technologies. Also includes level switches for alarm and control functions.
- Pressure Measurement: Including pressure transmitters (gauge, absolute, differential), pressure switches with adjustable setpoints, pressure gauges (analog and digital), and pressure relief devices. Special considerations are given for diaphragm seals to handle corrosive or viscous process fluids.
- Temperature Measurement: Supporting a range of temperature sensing technologies, including RTDs (resistance temperature detectors), thermocouples (various types - J, K, T, etc.), thermistors, and filled-system thermometers. Components include sensors, transmitters, and thermowells designed for specific process conditions.
- Weight Measurement: Enabling gravimetric measurement with strain gauge load cells, bending beam load cells, compression load cells, and tension load cells. Systems covered also include weight transmitters, indicators, and controllers for batching, blending, and continuous weighing applications.
Key Features:
- ISA TR20 Compliance for Standardized Documentation
- User-Friendly Excel Format with Full Customization
- Extensive Device Coverage for Comprehensive Design
- Enhanced Data Accuracy and Consistency
- Accelerated Specification Development
Optimize your Designs and Boost Efficiency:
Simplify your instrument and control system design workflow and enhance engineering efficiency with IndustryDocs ISA TR20 Compliant Excel Datasheets. Experience the power of structured, user-friendly instrumentation documentation tailored for design and process engineers.
Learn More and Purchase: ISA TR20 Compliant Instrument and Control Datasheets
